TMS320F28335PGFA Digital Integrated Circuits
Product Description
TMS320F28335, a high-performance 32-bit floating-point DSP controller from Texas Instruments (TI). It belongs to the TMS320C28X series, with 150MHz high-speed processing capability, with 32-bit floating-point processing unit, 6 DMA channels to support ADC, McBSP and EMIF, with up to 18 PWM outputs, of which 6 are TI's unique higher precision PWM outputs (HRPWM), and a 12-bit, 16-channel ADC. this DSP is in keeping the 150MHz clock rate unchanged, compared with TI's previous generation of leading digital signal controllers, the performance of this DSP, on average, 50% higher.
Product Parameters
Model: TMS320F28335PGFA LQFP176 32-bit Digital signal processing chip.
Model Parameter Description: With 150MIPS, FPU, 512KB flash memory, EMIF，12 bit ADC the C2000™ 32-bit MCU.
Parameter Description:
| Program storage capacity | 256KB |
| Total RAM capacity | 34KB |
| Maximum CPU frequency | 150MHz |
| Number of GPIO ports | 88 |
| Working voltage range | 1.805V~1.995V |
Product Advantages
1. High performance: TMS320F28335 has 150MHz high-speed processing capability, 32-bit floating-point processing unit, which can quickly handle complex algorithms and signal processing tasks.
2. Versatility: The chip has a rich set of peripheral interfaces, including PWM, ADC, CAN, SCI, etc., which is suitable for controllers, power supply, motor control, communication and other fields.
3. Easy to develop: Programmed in C language, it has a complete development tool chain and a rich code library, which is convenient for developers to develop and debug. Low Power Consumption.
4. Low power consumption: low-power design, support for a variety of power consumption modes, able to run for a long time in a battery-powered environment. High precision: with fixed-point DSP, it is easy for developers to develop and debug.
5. High precision: Compared with the fixed-point DSP, TMS320F28335 has higher precision, simplifying software development, and is compatible with the fixed-point C28x controller software, shortening the development cycle and reducing development costs.
6. High integration: On-chip integration of large-capacity memory and a wealth of peripherals, such as 12-bit 16-channel ADC, 6 DMA channels to support ADC, McBSP and EMIF, up to 18 PWM outputs, of which 6 for the TI-specific higher-precision PWM outputs (HRPWM).
7. High peripheral integration: Integrated a variety of peripherals, such as I2C, SPI, eCAN, ePWM, etc., suitable for a variety of control class industrial equipment.
8. Strong environmental adaptability: Meet the high and low temperature, vibration requirements, to meet the industrial environment applications High environmental adaptability.
