PowerEdge R760 Rack Mounted Server
Product Role and Benefits
1.Excellent computing performance: By utilizing fully optimized configurations, we provide outstanding computing performance to help users seize the opportunity.
2.Supports the latest processors: Supports two 4th generation Intel processors ® xeon ® Scalable processor, each processor can be configured with up to 56 cores, providing faster and more accurate processing performance.
3.DDR5 memory support: Supports up to 32 DDR5 DIMMs, accelerates workloads in memory, and provides higher memory bandwidth.
4.GPU support: Supports 2 dual width GPUs or 6 single width GPUs, suitable for workloads that require acceleration.
5.Intelligent streaming chassis design: optimized ventilation, supports high core count CPUs, and provides peak performance air cooling.
6.Flexible storage options: Supports multiple storage configurations, including 2.5-inch and 3.5-inch hard drives, as well as NVMe drives.
7.Network resilience architecture: Built in security, including protected supply chain and factory to site integrity assurance.
8.Efficient System Management: Through Dell OpenManage ™ The system management product portfolio simplifies, automates, and centralizes one to many management.
9.Sustainable development: Adopting recycled materials and energy-efficient innovative options to reduce carbon emissions and lower operating costs.
10.Comprehensive service support: providing consultation, ProDeploy and ProSupport suites, data migration, and other comprehensive services.
Product Application Areas
1.Standardization of mixed workloads: The R760 is capable of handling various workloads and is an ideal choice for deploying mixed workloads in enterprises.
2.Database and Analysis: With its powerful computing power and optimized storage performance, the R760 is highly suitable for database and analysis applications, providing fast data access and processing capabilities.
3.Virtual Desktop Infrastructure (VDI): The R760 supports a large amount of memory and high-speed storage, making it suitable as a backend for virtualization environments and providing support for virtual desktops.
4.Artificial Intelligence and Machine Learning: The R760 supports the latest processors and high-speed memory, providing the necessary computing power for AI and machine learning workloads.
5.File and object storage: The R760xd2 model is particularly suitable for file and object storage, video capture/retrieval, and content delivery networks, providing faster storage, retrieval, and excellent scalability.
6.Video capture and retrieval: The design of the R760xd2 model enables it to perform excellently in video capture and retrieval, capable of handling large amounts of unstructured data.
7.Content Delivery Network (CDN): R760xd2 provides a powerful storage solution suitable for building and maintaining content delivery networks.
Product Operation Guide
The specific operation steps and detailed configuration may vary depending on the specific model and configuration of the system. It is recommended to refer to the official documentation and user manual provided by Dell for operation.
Product After-Sales Service
Firstly, locate the service number of the server, which can usually be found on the label on the back or bottom of the server. You can contact customer service through phone, online email, and other means. If you need to replace parts or repair, you can visit Dell's parts and repair page to view available parts and repair options.
